滾珠絲杠是工具機和精密機械上常使用的傳動元件，其主要功能是將旋轉運動轉換成線性運動，或?qū)⑴ぞ剞D(zhuǎn)換成軸向反覆作用力，同時兼具高精度、可逆性和高能效率的特點。下面導軌絲杠廠家來介紹下滾珠絲杠的維修情況。

Ball screw is a commonly used transmission component in tool machines and precision machinery. Its main function is to convert rotational motion into linear motion or torque into axial repetitive force, while also possessing the characteristics of high precision, reversibility, and high energy efficiency. Below, the manufacturer of the guide screw will introduce the maintenance status of the ball screw.

一：清洗、加潤滑油脂、調整絲杠和滾珠螺母之間隙;

1： Clean, add lubricating grease, adjust the gap between the screw and ball nut;

二：更換滾珠絲杠和螺母之間滾動體(鋼球);

2： Replace the rolling element (steel ball) between the ball screw and nut;

三：更換滾珠螺母;

3： Replace the ball nut;

四：更換滾珠螺母循環配件(循環管或換向器);

4： Replace the ball nut circulation accessory (circulation tube or commutator);

五：研磨已經磨損的滾珠絲杠和滾珠螺母的溝道使其達到用戶的使用精度;

5： Grind the worn groove of the ball screw and ball nut to meet the user's usage accuracy;

六：提供滾珠絲杠的精度檢測服務，使客戶及時了解到設備的狀態，從而提高生產效率，大大降低了由于設備的故障所帶來的損失;

6： Provide precision testing services for ball screws, enabling customers to timely understand the status of equipment, thereby improving production efficiency and greatly reducing losses caused by equipment failures;

七：滾珠絲杠的替換服務。

7： Replacement service for ball screws.

滾珠絲桿進給單元的固有頻率受到支承方式的影響：兩端固定時其各階固有頻率明顯高于一端固定一端簡支的各階固有頻率。

The natural frequency of the ball screw feed unit is affected by the support method: when both ends are fixed, the natural frequencies of each order are significantly higher than those of each order when one end is fixed and one end is simply supported.

滾珠絲桿進給單元的固有頻率受到螺母位置的影響：螺母位于絲杠固定端時的各階固有頻率比螺母位于絲杠簡支端時的各階固有頻率要高,螺母位于絲杠兩端時的各階固有頻率明顯低于螺母位于絲杠中間位置時的各階固有頻率。

The natural frequency of the ball screw feed unit is influenced by the position of the nut: the natural frequencies of each order when the nut is located at the fixed end of the lead screw are higher than those when the nut is located at the simply supported end of the lead screw. The natural frequencies of each order when the nut is located at both ends of the lead screw are significantly lower than those when the nut is located in the middle position of the lead screw.

考慮直線導軌副的滾珠絲杠進給單元的各階固有頻率要比不考慮直線導軌的滾珠絲杠進給單元的各階固有頻率更接近于試驗結果,更加符合進給單元的實際真實情況。還有什么事項就來我們網站http://www.pet998.com咨詢！

The natural frequencies of each order of the ball screw feed unit considering the linear guide pair are closer to the experimental results than those of the ball screw feed unit without considering the linear guide, which is more in line with the actual situation of the feed unit. If there are any other matters, please come to our website http://www.pet998.com consulting service
