Guide screw: a new building material tool, which is used to transfer the overall lifting stress of the building and adjust the support, including: support rod, reinforcing rib, support surface. The support rod is fixed below the support surface, and the fixing and connection between the reinforcing rib and the support rod. It is equipped with an adjusting screw at the lower end of each support rod, and a slot shaped sliding base is set above the support surface, A sliding plate is placed in the sliding base and an adjusting lead screw is set at one side. The end of the adjusting lead screw is against the sliding plate, and the sliding plate can slide under the action of the lead screw. The sliding plate has the characteristics of stable and reliable stress transfer of the support, and convenient position offset adjustment when the building is raised.

導軌絲杠特點：

Features of guide screw:

1、按照國標GB/T17587.3-1998及應用實例，滾珠絲杠（已基本取代

1. According to the national standard GB/T17,587.3-1998 and application examples, the ball screw (basically replaced

雄聯滾珠絲杠圖片(4張)

Pictures of Xionglian ball screw (4)

梯形絲桿，俗稱絲桿）是用來將旋轉運動轉化為直線運動；或?qū)⒅本€運動轉化為旋轉運動的執行元件，并具有傳動效率高，定位準確等

Trapezoidal screw rod, commonly known as screw rod) is used to convert rotary motion into linear motion; Or it can convert linear motion into rotary motion, with high transmission efficiency, accurate positioning, etc

2、當滾珠絲杠作為主動體時，螺母就會隨絲桿的轉動角度按照對應規格的導程轉化成直線運動，被動工件可以通過螺母座和螺母連接，從而實現對應的直線運動。

2. When the ball screw is used as the active body, the nut will be converted into linear motion according to the lead of the corresponding specification with the rotation angle of the screw rod, and the passive workpiece can be connected with the nut through the nut seat, thus realizing the corresponding linear motion.

應用

application

超DN值滾珠絲杠：高速工具機，高速綜合加工機

Ball screw exceeding DN value: high-speed tool machine, high-speed integrated machining center machine

端蓋式滾珠絲杠：快速搬運系統，一般產業機械，自動化機械

End cap ball screw: quick handling system, general industrial machinery, automation machinery

高速化滾珠絲杠：CNC機械、精密工具機、產業機械、電子機械、高速化機械

High speed ball screw: CNC machinery, precision tool machine, industrial machinery, electronic machinery, high speed machinery

精密研磨級滾珠絲杠：CNC機械，精密工具機，產業機械，電子機械，輸送機械，航天工業，其它天線使用的致動器、閥門開關裝置等

Precision grinding ball screw: CNC machinery, precision tool machine, industrial machinery, electronic machinery, conveying machinery, aerospace industry, actuators and valve switches for other antennas

螺帽旋轉式（R1）系列滾珠絲杠：半導體機械、產業用機器人、木工機、雷射加工機、搬送裝置等

Screw cap rotary (R1) series ball screw: semiconductor machinery, industrial robots, woodworking machines, laser processing machines, conveying devices, etc

軋制級滾珠絲杠：低摩擦、運轉順暢的優點，同時供貨迅速且低廉

Rolling grade ball screw: low friction, smooth operation, fast supply and low price

重負荷滾珠絲杠：全電式射出成形機、沖壓機、半導體制造裝置、重負荷制動器、產業機械、鍛壓機械

Heavy duty ball screw: full electric injection molding machine, stamping machine, semiconductor manufacturing device, heavy duty brake, industrial machinery, forging machinery

以上就是為大家介紹的有關導軌絲杠的詳細的介紹,希望對您有所幫助.如果您有什么疑問的話,歡迎聯系我們.我們將以的態度,為您提供服務http://www.pet998.com

The above is a detailed introduction to the guide screw, and we hope it will be helpful to you. If you have any questions, please contact us. We will provide you with professional services http://www.pet998.com
